Pressure Balanced Expansion Joint

Product Description

Pressure Balanced Expansion Joint is a specially designed metal bellows expansion device used to absorb thermal expansion and vibration while eliminating or balancing pressure thrust forces generated by internal pipeline pressure.

Unlike conventional expansion joints, pressure balanced expansion joints use a balance bellows structure to counteract the pressure thrust, reducing the load transferred to connected equipment, anchors, and supports. They are ideal for pipelines where space limitations or equipment sensitivity require effective pressure force control.

It is widely used in power plants, petrochemical industries, steam pipelines, boiler systems, gas pipelines, and large industrial piping networks.

Key Features

Pressure Thrust Balance
The balanced bellows structure effectively compensates internal pressure forces and minimizes the reaction force on pipeline anchors.

Large Axial Movement Compensation
Designed to absorb significant axial thermal expansion while maintaining pipeline stability.

Protect Connected Equipment
Reduces stress on pumps, valves, turbines, and other sensitive equipment.

High Temperature & Pressure Resistance
Manufactured with high-quality stainless steel bellows for demanding industrial environments.

Flexible Installation Options
Suitable for complex pipeline layouts where conventional expansion joints cannot be installed.

Customized Design Available
Designed according to pipe size, pressure, temperature, movement requirements, and connection standards.

Applications

• Power Plant Steam Pipelines

• Boiler Main Steam Systems

• Turbine Connection Pipelines

• Petrochemical Process Pipelines

• Chemical Industry Systems

• Gas Transmission Pipelines

• Large Diameter Industrial Pipelines

• High Temperature Exhaust Systems

Common Types

• In-line Pressure Balanced Expansion Joint
  （直管压力平衡膨胀节）

• Elbow Pressure Balanced Expansion Joint
  （曲管压力平衡膨胀节）

• Universal Pressure Balanced Expansion Joint
  （复式压力平衡膨胀节）

• Axial Pressure Balanced Expansion Joint
  （轴向压力平衡膨胀节）

Technical Specifications

• Product Type: Pressure Balanced Bellows Expansion Joint

• Movement Type: Axial / Lateral / Combined Movement

• Bellows Material: Stainless Steel 304 / 316L / Alloy Steel

• Tie Rod Material: Carbon Steel / Stainless Steel

• Medium: Steam, Gas, Air, Hot Water, Chemical Media

• Connection: Flange Connection / Welding Connection

• Temperature Range: Customized According to Working Conditions

• Pressure Rating: Customized According to Pipeline Requirements

Advantages

• Eliminates excessive pressure thrust forces

• Reduces pipeline support and anchor loads

• Suitable for high-pressure pipeline systems

• Improves system safety and reliability

• Absorbs thermal expansion effectively

• Extends service life of connected equipment

• OEM and project customization available
